Video Bandwidth

2.25Gbps

Input Ports

4 × HDMI (Female type),1x RS232

Output Ports

1 × HDMI (Female type), 1xRCA

Audio output

PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1

Input Resolution

480i60Hz,480p60Hz,576i50Hz,576p50Hz,720p50/60Hz,

1080i50/60Hz,1080p24/30/50/60Hz,800x600@60, 1024x768@60,1280x720@60,1920x1080@60;

Output Resolution

1080p,1080i,720p,1024x768,1360x768

ESD Protection

Human Body model: ±8 kV (air-gap discharge)

±4 kV (contact discharge)

Power Supply

12 V/2.5A DC (US/EU standards, CE/FCC/UL certified)

Dimensions

118mm(W) X 250mm (D) X 32mm(H)

Weight

750 g

Chassis Material

Metal

Silkscreen Color

Black

Operating Temperature

0 °C~40 °C/ 32 °F~104 °F

Storage Temperature

−20 °C ~ 60 °C/−4 °F ~140 °F

Relative Humidity

20~90 % RH (non-condensing)

Power Consumption

10 W
